Diazo and Drafting
We supply technical papers and films for manual drafting and tracing. If you need printed tracing papers or white opaque rolls: Just tell us. If highest dimension stability is required, we suggest to check our polyester films double matt.
Even today in the CAD-times there are many reasons to choose Ammonia Diazo Printing process. We supply the machines and the papers and we have a wide range of semi-dry media.
Our Product Range:
-
•Ammonia Diazo Printing Paper (Rolls and Sheets in different speeds, thicknesses and dimensions)
-
•Matai Ammonia Diazo Printing Machine ECO-DIAZO-NM with Filter Absorber. Working width: 120 cm, 3-Lamps, adjustable speed
-
•Diazo lacquered transparent paper (extra strong)
-
•Ammonia Specialities (Diazo Cardboard, diazo mounted cloth, double sided)
-
•Polyester Diazo printing films
-
•Semi-Dry Diazo printing paper Rolls and Sheets in different thicknesses and dimensions
-
•Semi-Dry lacquered transparent paper
-
•Polyester films for Semi-Dry Process
-
•Semi-Dry Developer (Powder or concentrate)
-
•Tracing Paper in 90/95 or 110/115 g/m2 Rolls and Sheets in many different dimensions
-
•Millimeter Tracing Paper
-
•Polyester-Drafting Film (different gauges, one side matt or double sided matt)
-
•electric (Electro-Jet 150) and manual (Jet-2000) Matai Paper Trimmers
Details and Qualities
Ammonia Daizo Printing Papers
-
•S1-80 (black line/standard speed), 80 g/m2:
65 cm x 20 m – Art.-No. 470101
75 cm x 20 m – Art.-No. 470102
90 cm x 20 m – Art.-No. 470103
100 cm x 20 m – Art.-No. 470104
120 cm x 20 m – Art.-No. 470105
65 cm x 50 m – Art.-No. 470107
90 cm x 50 m – Art.-No. 470109
29,7 cm x 100 m – Art.-No. 470112
42 cm x 100 m – Art.-No. 470113
59,4 cm x 100 m – Art.-No. 470114
65 cm x 100 m – Art.-No. 470115
84,1 cm x 100 m – Art.-No. 470116
90 cm x 100 m – Art.-No. 470117
100 cm x 100 m – Art.-No. 470118
A4 (21 cm x 29,7 cm) – 500 sheets – Art.-No. 470134
A3 (29,7 cm x 42 cm) – 250 sheets – Art.-No. 470133
A2 (42 cm x 59,4 cm) – 250 sheets – Art.-No. 470132
A1 (59,4 cm x 84,1 cm) – 250 sheets – Art.-No. 470131 -
•S2-80 (black line/fast speed), 80 g/m2:
33 cm 20 m – Art.-No. 470200
65 cm x 20 m – Art.-No. 470201
75 cm x 20 m – Art.-No. 470202
90 cm x 20 m – Art.-No. 470203
100 cm x 20 m – Art.-No. 470204
120 cm x 20 m – Art.-No. 470205
65 cm x 50 m – Art.-No. 470207
75 cm x 50 m – Art.-No. 470208
90 cm x 50 m – Art.-No. 470209
100 cm x 50 m – Art.-No. 470210
120 cm x 50 m – Art.-No. 470211
A4 (21 cm x 29,7 cm) – 500 sheets – Art.-No. 470234
A3 (29,7 cm x 42 cm) – 250 sheets – Art.-No. 470233
A2 (42 cm x 59,4 cm) – 250 sheets – Art.-No. 470232
A1 (59,4 cm x 84,1 cm) – 250 sheets – Art.-No. 470231
77 cm x 103 cm – 100 sheets – Art.-No. 470235
A0 (84,1 cm x 118,9 cm) – 125 sheets – Art.-No. 470230 -
•S3-80 (black line, ultra fast speed), 80 g/m2
33 cm 20 m – Art.-No. 470300
65 cm x 20 m – Art.-No. 470301
75 cm x 20 m – Art.-No. 470302
90 cm x 20 m – Art.-No. 470303
100 cm x 20 m – Art.-No. 470304
120 cm x 20 m – Art.-No. 470305
65 cm x 50 m – Art.-No. 470307
75 cm x 50 m – Art.-No. 470308
90 cm x 50 m – Art.-No. 470309
100 cm x 50 m – Art.-No. 470310
59,4 cm x 100 m – Art.-No. 470314
84,1 cm x 100 m – Art.-No. 470316
90 cm x 100 m – Art.-No. 470317
A4 (21 cm x 29,7 cm) – 500 sheets – Art.-No. 470334
A3 (29,7 cm x 42 cm) – 250 sheets – Art.-No. 470333
A2 (42 cm x 59,4 cm) – 250 sheets – Art.-No. 470332
A1 (59,4 cm x 84,1 cm) – 250 sheets – Art.-No. 470331 -
•B2-80 (blue line, fast speed), 80 g/m2
65 cm x 20 m – Art.-No. 470250
75 cm x 20 m – Art.-No. 470251 -
•R3-80 (red line, ultra fast speed), 80 g/m2
65 cm x 20 m – Art.-No. 470350
90 cm x 20 m – Art.-No. 470351 -
•S2-110 (black line, fast speed), 110 g/m2
65 cm x 20 m – Art.-No. 470271
90 cm x 20 m – Art.-No. 470273
100 cm x 20 m – Art.-No. 470274 -
•TW-ES (Diazo lacquered transparent ammonia printing paper, extra strong), 110/115 g/m2
65 cm x 20 m – Art.-No. 470400
90 cm x 20 m – Art.-No. 470402
100 cm x 20 m – Art.-No. 470403
120 cm x 20 m – Art.-No. 470404 -
•AUF GEWEBE (diazo mounted cloth, black line), 175 g/m2
75 cm x 10 m – Art.-No. 470700
100 cm x 10 m – Art.-No. 470701 -
•S1-110-DS (double sided ammonia diazo printing paper), 110 g/m2
75 cm x 20 m – Art.-No. 470710
100 cm x 20 m – Art.-No. 470711
77 cm x 103 cm – 100 Bl. – Art.-No. 472719
79 cm x 103 cm – 100 Bl. – Art.-No. 472721 -
•SL-1-210 (extra strong, black line), 210 g/m2
100 cm x 10 m – Art.-No. 470716 -
•POL-LPF-70-DM (Polyester Ammonia Diazo film, double matt, black line), 0,07 mm
65 cm x 20 m – Art.-No. 470500
90 cm x 20 m – Art.-No. 470502
100 cm x 20 m – Art.-No. 470503
120 cm x 20 m – Art.-No. 470504
A4 (21 cm x 29,7 cm) – 100 sheets – Art.-No. 470554
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 470553
A2 (42 cm x 59,4 cm) – 100 sheets – Art.-No. 470552
A1 (59,4 cm x 84,1 cm) – 100 sheets – Art.-No. 470551
A0 (84,1 cm x 118,9 cm) – 100 sheets – Art.-No. 470550 -
•POL-LPF-100-DM (Polyester Ammonia Diazo film, double matt, black line), 0,1 mm
65 cm x 20 m – Art.-No. 470600
90 cm x 20 m – Art.-No. 470602
100 cm x 20 m – Art.-No. 470603
120 cm x 20 m – Art.-No. 470604
A4 (21 cm x 29,7 cm) – 100 sheets – Art.-No. 470654
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 470653
A2 (42 cm x 59,4 cm) – 100 sheets – Art.-No. 470652
A1 (59,4 cm x 84,1 cm) – 100 sheets – Art.-No. 470651
A0 (84,1 cm x 118,9 cm) – 100 sheets – Art.-No. 470650 -
•other films of different gauges, sepia line or clear films are available in different dimensions on request.
Semi-Dry Diazo Paper (Ammonia-free Development)
-
•HF-2-80 (fast speed, black line), 80 g/m2
65 cm x 20 m – Art.-No. 472101
90 cm x 20 m – Art.-No. 472103
100 cm x 20 m – Art.-No. 472104
120 cm x 20 m – Art.-No. 472105
65 cm x 50 m – Art.-No. 472108
90 cm x 50 m – Art.-No. 472111
100 cm x 50 m – Art.-No. 472112
A4 (21 cm x 29,7 cm) – 500 Bl. – Art.-No. 472135
A3 (29,7 cm x 42 cm) – 250 Bl. – Art.-No. 472136
A2 (42 cm x 59,4 cm) – 250 Bl. – Art.-No. 472137
A1 (59,4 cm x 84,1 cm) – 250 Bl. – Art.-No. 472138
A0 (84,1 cm x 118,9 cm) – 125 Bl. – Art.-No. 472139 -
•HF-90 (fast speed, black line, high quality), 90 g/m2
65 cm x 30 m – Art.-No. 472121
90 cm x 30 m – Art.-No. 472122 -
•HF-2-110 (fast speed, black line, extra strong), 110 g/m2
65 cm x 20 m – Art.-No. 4721331
90 cm x 20 m – Art.-No. 472132 -
•HQ-HF-TRANSP-115 (Diazo lacquered transparent paper, extra strong) 110/115 g/m2
65 cm x 30 m – Art.-No. 472400
90 cm x 30 m – Art.-No. 472401 -
•HF-FOL-ES (Semi-Dry Polyester Diazo Film), 0,1 mm
65 cm x 20 m – Art.-No. 472500
90 cm x 20 m – Art.-No. 472501
100 cm x 20 m – Art.-No. 472502
120 cm x 20 m – Art.-No. 472503 -
•Developer for Semi-Dry Diazo Papers and Films:
HF-Developer Powder (1 bag for 1 l) – Art.-No. 472600
HF-Concentrate (1 bottle of 0,5 l) – Art.-No. 472601
Océ D-Concentrate (1 bottle of 0,5 l) – Art.-No. 472602
Drafting Technology:
Transparent Tracing Papers
-
•TZP-90/95 (tracing paper, transparent), 90/95 g/m2
66 cm x 20 m – Art.-No. 480300
91 cm x 20 m – Art.-No. 480302
110 cm x 20 m – Art.-No. 480303
150 cm x 20 m – Art.-No. 480304
66 cm x 50 m – Art.-No. 480305
91 cm x 50 m – Art.-No. 480306
110 cm x 50 m – Art.-No. 480307
A4-pad, 50 sheets – Art.-No. 472106
A3-pad, 50 sheets – Art.-No. 470107
A4-sheets, 250 sheets – Art.-No. 160020
A3-sheets, 250 sheets – Art.-No. 160021 -
•TZP-110/115 (tracing paper, transparent), 110/115 g/m2
66 cm x 20 m – Art.-No. 480500
91 cm x 20 m – Art.-No. 480501
110 cm x 20 m – Art.-No. 480502
66 cm x 50 m – Art.-No. 480503
91 cm x 50 m – Art.-No. 480504
110 cm x 50 m – Art.-No. 480505
A4-pad, 50 sheets – Art.-No. 472109
A3-pad, 50 sheets – Art.-No. 470110
A4-sheets, 250 sheets – Art.-No. 160030
A3-sheets, 250 sheets – Art.-No. 160031 -
•TZP-40/45 (tracing paper, transparent), 40/45 g/m2
33 cm x 50 m – Art.-No. 480001
61 cm x 50 m – Art.-No. 480002 -
•TZP-24 (Sketch paper), 24 g/m2
33 cm x 50 m – Art.-No. 480605
61 cm x 50 m – Art.-No. 480606
33 cm x 100 m – Art.-No. 480607
61 cm x 100 m – Art.-No. 480608
Polyester Drafting Films -
•POL-ZF-70-DM, double matt, 0,07 mm
65 cm x 20 m – Art.-No. 470800
90 cm x 20 m – Art.-No. 470801
100 cm x 20 m – Art.-No. 470802
120 cm x 20 m – Art.-No. 470803
A4 (21 cm x 29,7 cm) – 100 sheets. – Art.-No. 470854
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 470853
A2 (42 cm x 59,4 cm) – 100 sheets – Art.-No. 470852
A1 (59,4 cm x 84,1 cm) – 100 sheets – Art.-No. 470851
A0 (84,1 cm x 118,9 cm) – 100 sheets – Art.-No. 460850 -
•POL-ZF-100-DM, double matt, 0,1 mm
65 cm x 20 m – Art.-No. 470820
90 cm x 20 m – Art.-No. 470821
100 cm x 20 m – Art.-No. 470822
120 cm x 20 m – Art.-No. 470823
120 cm x 50 m – Art.-No. 470824
130 cm x 20 m – Art.-No. 470899
A4 (21 cm x 29,7 cm) – 100 sheets – Art.-No. 470874
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 470873
A2 (42 cm x 59,4 cm) – 100 sheets – Art.-No. 470872
A1 (59,4 cm x 84,1 cm) – 100 sheets – Art.-No. 470871
A0 (84,1 cm x 118,9 cm) – 100 sheets – Art.-No. 460870 -
•POL-ZF-150-DM, double matt, 0,15 mm
60 cm x 20 m – Art.-No. 470832
90 cm x 20 m – Art.-No. 470830
120 cm x 20 m – Art.-No. 470831
A4 (21 cm x 29,7 cm) – 100 sheets – Art.-No. 470876
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 470875 -
•POL-ZF-100-SM, single matt, 0,1 mm
A4 (21 cm x 29,7 cm) – 100 sheets – Art.-No. 372610
A3 (29,7 cm x 42 cm) – 100 sheets – Art.-No. 372600
Other qualities or dimensions are available on request.
We supply media for classical reprographic processes and help you suitable Diazo-printing machine and paper trimmers. Please contact us for details, brochures etc.
